TOPSE0700WD Product Guide.
TOPSE0700WD
- Certification
-
-
Dual Core CPU
Cost-effective dual core CPU for universal usage
-
16M Full Color
Bright full color graphics
-
High Resolution
1024 x 600 high resolution in 7 inch screen
-
All-in-one body with a sleek design
Premium all-in-one design
for an elegant look and easy handling
-
Optimized Interface Configuration
2 serial channels, 1 Ethernet port, 1 USB port
- Display
- 7" 16:9 TFT 16M Color LCD
- Serial COM1
- RS-232C, RS-422/485 Asynchronous
Data bit : 7/8 bits
Stop bit : 1/2 bits
Parity bit : None/Odd/Even
Baud rate : 2400~115.2kbps
Connector : DSUB 9pin
- Serial COM2
- RS-485 Asynchronous
Data bit : 7/8 bits
Stop bit : 1/2 bits
Parity bit : None/Odd/Even
Baud rate : 2400~115.2kbps
Connector : 2pin connector
- Serial COM3
- RS-232C Asynchronous
Data bit : 7/8 bits
Stop bit : 1/2 bits
Parity bit : None/Odd/Even
Baud rate : 2400~115.2kbps
Connector : DSUB 9pin
- Ethernet
- IEEE802.3i/IEEE802.3u 10BASE-T/100BASE-TX
Connector : RJ45 x 1
- USB Host
- USB 2.0 Compatible
Connector : USB Type A x 1
- USB OTG
- USB 2.0 Compatible
Connector : USB Type C x 1
- Memory
- 256MB DDR3, 25BMG Flash ROM
- Structure
- Panel Cut : 190 × 136
External Dimension : 204×145×36.6
Weight : 476g
Case : PC
